Applications:

1. Thermal insulation and soundproofing material for car

Material: XPE
Density: 30B (33 kg/m³)
Thickness: 3mm, 4mm, 5mm
Processing method: Adhesive (Included)
Advantage: Adhesive foam for easy decroration, have good soundproof and thermal insulation performance. Fire retardant is available.

2. Acoustic material for floor

Material: XPE, IXPE Foam
Density: 10B (100 kg/m³), 15B (66 kg/m³)
Thickness: 5mm, 6mm, 7mm
Processing method: Heat pressing and seaming
Advantage: It's used in the middle layer of car floor. The most common product is combination of PVC materials. Easy to process and laminate with other materials to enhance waterproof and insulating properties.

3. Automobile sunshade Board Material

Material: XPE, IXPE Foam

Density: 20B (50 kg/m³), 25B (40 kg/m³), 30B (33 kg/m³)
Thickness: 5mm
Processing method: Heat pressing
Advantage: Excellent insulation materials and building-up properties.

4. Damping pad for car trunk

Material: IXPE, XPE Foam
Density: 30B (33 kg/m³), 35B(28 kg/m³)
Thickness: 3mm, 4mm, 5mm, 6mm
Processing method: Heat pressing
Advantage: Extremely easy to cut into the size you want with shockproof protection and noise reduction properties.

5. Ceiling vibration damping material for car roof liner

Material: IXPE, IXPP
Density: 15B(66 kg/m³)
Thickness: 4mm, 5mm
Processing method: Heat pressing & die cutting
Advantage: Processing with flexible IXPE or IXPP foam material to prevent vibration and reduce the heat.

6. Sound deadening material for car door panels

Material: XPE, IXPE Foam
Density: 8B (125 kg/m³), 10B (100 kg/m³), 15B (66 kg/m³), 20B (50 kg/m³)
Thickness: 2mm, 3mm, 4mm
Application: Door waterproof strip, water-repellent film
Processing method: Thermal vacuum forming
Advantage: The closed cell foam structure provides noise reduction and excellent waterproof property.

Features

(1) Water durable: Closed-cell foam, non-water-absorbing, moisture-proof.

(2) Rot resistant: Seawater, oil, acid and alkali durable; Antibacterial, safe, odorless and
non-polluting.

(3) Easy processing: Continuous; Easy hot-press shaping, casting, gluing and joining.

(4) Shockproof: Good flexibility and anti-hardening; Excellent shockproof and cushion capability.

(5) Heat preservation: Excellent heat insulation, anti-cold, non-frosting and insulation
enduring capabilities.

(6) Sound insulation: Closed-cell foam, good sound insulation capability.

Advantages

1. Light weight, good elasticity
2. Weatherproof and waterproof
3. Flame retardant
4. Sound absorption
5. Heat insulation
6. Thermal insulation
7. Elastic and flexibility
8. Shock absorption

Specifications

Foam Dimension-the thickness ,width and length ,they all can be customize.

Foam color-Foam is color-coded during the manufacturing process for meet customer needs,normal colored black and white.It can be customized as long as you advise the Pantone Num.

HICKNESS, single layer sheeting of 0.5-15mm, and also laminating multiple layers of sheets up to 80mm.

WIDTH, produced in roll form of 1.0M – 1.8M, depending on foam density and thickness.

MOQ

1) 1mm-3mm thickness, MOQ3000sqm

2)4mm-7mm thickness, MOQ 2000 sqm

3)Thickness more than 8mm,MOQ 1000 sqm

Delivery date from the Date of Order:15-20 workingdays

our services

Factory direct selling with competitve price, sooner leadtime,better customized services.
Samples in stock can be arranged in one working day.

Company info

CYG TEFA Co., Ltd has 17 years of production experience. We're the biggest and the most professional irradiation cross-linked polyethylene conductive foam manufacturer in China and has the most complete cross-linked polyethylene foam products. Our main products are Cross-linked PE foam material, IXPE foam, XPE foam, Conductive IXPE foam; ESD foam tray, ESD packing material; Beach mat, camping mat, sleeping mat, yoga mat; etc. Our clients are iPhone, Samsung, Gree, Haier, TCL, Adidas, Nike, Flextronics, General Motors, BYD, PPL, etc. Now, we have 2 factories and 17 production lines...

CYG Tefa Co., Ltd Since 2002, is a national high-tech enterprise,one of the subsidiaries of woer.

Factories: 2 factories with more than 50 varity of production lines, located in HUIZHOU near Hongkong , Huzhou near Shanghai and Zhejiang near Shanghai.

Product Range: Crosslinked Closed cell PE foam, IXPE foam, IXLPE foam, XPE foam, XLPE foam, IXPP foam, ESD PE foam and solutions

Certifications: ISO9001, ISO14001, IATF16949,FMVSS 302,UL94 HF-1,RoHS,CE,etc.

Applications: Automotive NVH, Air condition insulation, HVAC, Construction insulation, Sports products

Capacity: 15000 tons per year
