Eco-friendly Closed Cell Ldpe Fire Resistant Ixpe Foam Material
Product description
| PE Foam Brief Introduction |
| Product name | Xpe foam | Ixpe foam |
| Material | Ldpe,(low density polyethylene foam) Ac foaming agent,cross-linking agent,etc | Ldpe,(low density polyethylene foam) Ac foaming agent,etc |
| Structure | Closed cell,cross-linked(by cross-linking agent) | Closed cell,cross-linked(irradiated) |
| Density | 25~330 kg/m3 | 25~330 kg/m3 |
| One layer thickness | 2mm~3mm(Density:67~330kg/m3) | 0.5~10mm(Density:25~330kg/m3) |
| Laminated thickness | 1)10mm(25~100kg/m3) 2)12mm(25~40kg/m3) 3)customized | Customized |
| Laminated with | Pe foam/Pure Alu/Aluminizing |
| Size | customized |
| Color | Normal is black,white,gray. Other color can be customized. |
| Shape | Roll or sheet |
| Adhesive | Available |
| Fire resistance | Available (UL94-1) |
Specification
| Density | 200±30 | 125±15 | 100±10 | 66.7±8 | 50±6 | 40±4 | 33.3±3 |
| Hardness | 60-70 | 50-60 | 45-50 | 35-45 | 30-35 | 2-30 | 18-25 |
Water absorption (23°C 24h)g/ cm³ | ≤0.02 | ≤0.02 | ≤0.03 | ≤0.03 | ≤0.04 | ≤0.04 | ≤0.05 |
| Thermal conductivity | ≤0.092 | ≤0.082 | ≤0.07 | ≤0.062 | ≤0.053 | ≤0.047 | ≤0.041 |
| Tensile strength(mpa) | L | ≥1.35 | ≥1.12 | ≥0.88 | ≥0.68 | ≥0.39 | ≥0.33 | ≥0.25 |
| M | ≥1.08 | ≥0.89 | ≥0.71 | ≥0.56 | ≥0.33 | ≥0.25 | ≥0.20 |
| Tesibility | L | ≥260 | ≥230 | ≥210 | ≥190 | ≥170 | ≥160 | ≥140 |
| M | ≥220 | ≥200 | ≥185 | ≥170 | ≥150 | ≥135 | ≥130 |
| Tearing strength | L | ≥5.90 | ≥4.80 | ≥3.60 | ≥2.80 | ≥1.80 | ≥1.60 | ≥1.35 |
| M | ≥7.10 | ≥5.40 | ≥4.00 | ≥3.30 | ≥2.30 | ≥2.00 | ≥1.70 |
Advantages
• Densities of 24 kg/cbm to 330 kg/cbm
• Chemically or physically cross-linked
• Fine, uniform, and closed cellular structure
• Highly resistant to ageing and weathering
• High chemical resistance
• Low flammability, electrically conductive or anti-static
Our services
Factory direct selling with lower price, sooner leadtime, better
customized service.
Samples in stock can be arranged in one working day.
Company info
CYG Main Product:
Cross-linked PE foam material, IXPE foam, XPE foam, Conductive IXPE foam; ESD foam tray, ESD
packing material; Beach mat, camping mat, sleeping mat, yoga mat; etc.
Years Of Experience
17 years of production experience.
Scale Of Factory
17 production lines :9 production lines in Shenzhen and 8 production lines in Huzhou .
Production Capacity
Annual 6000 tons
Why choose us
1.The biggest and the most professional irradiation cross-linked polyethylene conductive foam manufacturer in China
2.The most complete cross-linked polyethylene foam products.
3.Certificate: UL, ISO, SGS, Rohs, Reach , CE
Cooperative Partner
iPhone, Samsung, Gree, Haier, TCL, Nike, Flextronics, General
Motors, BYD, PPL, etc.
CYG TEFA offers the best solution for polyethylene foam production,
We supply PE foam in rolls, the length of each roll can be
customized to meet customer’s requirement.
The PE foam product can also be provided on the sheet as a request.
Here support foam die- Cutting,Lamination Adhesive ,Sheeting,
Perforating & Skiving.
All the service are focused on quality of products and satisfied
our customer.
