Polyethylene Foam Roll Air Conditioning Duct Insulation Thermal
Tnsulation Foam
- Saves Energy: retain the temperature of the air they are
transporting, reducing energy wastage.
- Prevents Condensation on Ducts: XPE insulation provides a solid
cover around the air ducts.
- Reduces Noise Transmitted Indoors: XPE can carry sound waves all
around the house and carry sounds across rooms such as the noise of
the furnace turning on in phases as well.
- Hot-dipped galvanized steel sheets of lock-forming quality are used
for the manufacturing of standard ducts.
- Ducts are also available in both, stainless steel and Aluminum.
- All straight ducts have beading all along at a distance of 300 mm
between them for reinforce.
Because of the XPE foam with the properties of good sound
absorption, heat insulation and flame
retardant, it is widely used in building as sound absorbent pad or
thermal barrier.
Specifications
- Foam Type: XPE FOAM / XLPE FOAM + AL Film + ADHESIVE
|
| Property | Standard | Unit | Value |
| Density | - | Kg/m³ | 33.33 |
| Tensile Strength | Transverse | ISO-1798 | MPa | 0.39~0.41 |
| Longitudinal | 0.23~0.28 |
| Tearing Strength | Transverse | ISO-8067
| Kn/m | 1.84~2.26 |
| Longitudinal | 1.32~1.40 |
| Compression 25% | ISO-3386-1 | kPa | 36.80 |
| Compression 45% | ISO-3386-1 | kPa | 66.70 |
| Compression 50% | ISO-3386-1 | kPa | 96.90 |
| Compression Set 25% 0.5H | ISO-1856 | % | 15.80 |
| Compression Set 25% 24H | ISO-1856 | % | 5.80 |
| Operating Temperature Range | Internal | °C | (-40,+80) |
| Water Absorption % Volume (Maximum) | Internal | % | 0.50 |
| Thermal Conductivity | JIS A1412-2 | W/mK | 0.040 |
| Shore - C | ASTM D2240 | °C | 23 |
| Flammability | FMVSS302 | mm/min | - |
Additional Information
● All tests were carried out in 23°C ± 2.
● Data represents typical values measured on a 15mm thick specimen
and should be considered as guidelines only.
● Processing method by eletronic heating.
● 12 kg/100m2 glue.
About CYG
CYG TEFA Co., Ltd, a national high-tech company, established in
December of 2002. Now we have 2 production bases in Shenzhen,
Hangzhou, Chongqing, 8 production lines of all kinds, with annual
production capacity of 6000 tons;
We are the leading manufacturer for XPE , IXPE foam,ESD foam for
more than 17 years, all our products can be used for thermal
insulation,waterproof,shockproof,etc. and also our products get the
UL, ISO, SGS, Rohs, Reach , CE approval. and we have 17 production
lines for production.Hope to cooperate with you.
- Management control system: Kingdee / OA / Oracle
IXPP project (three years: Proposal stage - Develop - Sampling -
Approved product- Small quantity supply for testing
11 employee
Investment rate: 4% to 10%
Responsible for : Improving available product / Technology
improving / New product development / New devices
FQA
1) How to guarantee your product quality?
We are a professional company engaged in the field more than 17
years with rich experience , advanced technology and high-tech
employees.
2)Could your products can meet our requirements?
Our products are produced according to customers' requirements,
size and color can be customized. If you have any question about
us, please feel free to contact us, we will response you as soon as
possible.
3)What's the advantage of your insulation?
Our insulation have good performance on heat-resistant, fireproof,
waterproof, heavy duty, lightweight, Eco-friendly and so on
4)What is difference between XPE and IXPE Foam?
XPE is chemical cross-linked, IXPE is physical type, which’s
surface is more smooth and cell size is smaller
than XPE. Also thickness evenness is better than XPE.
