Polythene Crosslink Pe Foam 1mm Thin Foam Sheet
Closed cell cross-linked polyethylene foam product is the main raw
material polyolefin, foam blowing agents and other additives have
been mixed, and then extruded through the extruder, through the
industrial electron accelerators produce high-energy electron beam
irradiation to Cross-linking (and therefore different from the
conventional chemical cross-linking, chemical cross-linking agent
DCP toxic), thus changing the molecular structure of polyolefins
into a tight three-dimensional network structure by free foam,
stereotypes, and a series of follow-up processing of integer
Process, to produce a high performance, high quality, delicate
appearance, feel comfortable, good performance of secondary
processing, non-toxic, tasteless grade closed-cell foam material.
Specification
| Density | 200±30 | 125±15 | 100±10 | 66.7±8 | 50±6 | 40±4 | 33.3±3 |
| Hardness | 60-70 | 50-60 | 45-50 | 35-45 | 30-35 | 2-30 | 18-25 |
Water absorption (23°C 24h)g/ cm³ | ≤0.02 | ≤0.02 | ≤0.03 | ≤0.03 | ≤0.04 | ≤0.04 | ≤0.05 |
| Thermal conductivity | ≤0.092 | ≤0.082 | ≤0.07 | ≤0.062 | ≤0.053 | ≤0.047 | ≤0.041 |
| Tensile strength(mpa) | L | ≥1.35 | ≥1.12 | ≥0.88 | ≥0.68 | ≥0.39 | ≥0.33 | ≥0.25 |
| M | ≥1.08 | ≥0.89 | ≥0.71 | ≥0.56 | ≥0.33 | ≥0.25 | ≥0.20 |
| Tesibility | L | ≥260 | ≥230 | ≥210 | ≥190 | ≥170 | ≥160 | ≥140 |
| M | ≥220 | ≥200 | ≥185 | ≥170 | ≥150 | ≥135 | ≥130 |
| Tearing strength | L | ≥5.90 | ≥4.80 | ≥3.60 | ≥2.80 | ≥1.80 | ≥1.60 | ≥1.35 |
| M | ≥7.10 | ≥5.40 | ≥4.00 | ≥3.30 | ≥2.30 | ≥2.00 | ≥1.70 |
Product description
| PE Foam Brief Introduction |
| Product name | Xpe foam | Ixpe foam |
| Material | Ldpe,(low density polyethylene foam) Ac foaming agent,cross-linking agent,etc | Ldpe,(low density polyethylene foam) Ac foaming agent,etc |
| Structure | Closed cell,cross-linked(by cross-linking agent) | Closed cell,cross-linked(irradiated) |
| Density | 25~330 kg/m3 | 25~330 kg/m3 |
| One layer thickness | 2mm~3mm(Density:67~330kg/m3) | 0.5~10mm(Density:25~330kg/m3) |
| Laminated thickness | 1)10mm(25~100kg/m3) 2)12mm(25~40kg/m3) 3)customized | Customized |
| Laminated with | Pe foam/Pure Alu/Aluminizing |
| Size | customized |
| Color | Normal is black,white,gray. Other color can be customized. |
| Shape | Roll or sheet |
| Adhesive | Available |
| Fire resistance | Available (UL94-1) |
Advantages
1)Waterproof: Closed-cell foam, non-water-absorbing,
moisture-proof.
2)Heat insulation: Closed cross linked structure, keep warm
3)Shockproof: Good flexibility and anti-hardening; Excellent
shockproof and cushion capability.
4)Sound insulation: Closed-cell foam, good sound insulation
capability.
5)Easy processing: Continuous; Easy hot-press shaping, casting,
gluing and joining.
6)No smelling,Non-toxic: Use ecologic material, RoHS approval
7)Soft and comfortable: Flexible with good elastic, stay the shape
soon after press
Mainly Application
Flotation,pool cover,surf bord
Our services
Factory direct selling with lower price, sooner leadtime, better
customized service.
Samples in stock can be arranged in one working day.
